| Printhead | 8-24 greyscalse inkjet printhead, 6-18pl | |
| Printing speed | Express mode | 160㎡/h |
| Production mode | 110㎡/h | |
| Quality mode | 80㎡/h | |
| Printing resolution | Up to 726*1440dpi | |
| Inkjet technology | On demand piezoelectricity inkjet mode, support gray level printing | |
| Ink | Using environmentally friendly, beautiful colors, high durability of outdoor LED ink | |
| Color | 6 Colors： C+M+Y+K+W+V | |
| Ink tank configuration | 2.5L | |
| RIP software configuration | Photoprint Flora Edition 19 | |
| Color control | International standard ICC color control, curve and density user adjustable functions | |
| File format | Tiff, Jepg, Postscript, EPS, Pdf，etc. | |
| Media system | ||
| Roll-to-roll loading | lamp box , light film, soft film, car stickers, PET, PVC and other coiled materials | |
| Conveyor belt | rigid media, acrylic board, corrugated board, wood board, kraft board, KT foam board, etc | |
| Media specifications | maximum width is 500cm, diameter 40cm and the weight is up to 300kg; rigid board size 500*250cm, 51mm thickness |
|
| Data transmission | ||
| Data interface | High speed USB transmission | |
| Machine size | ||
| Machine | 790*220*170cm | |
| Packing box | 810*240*235cm | |
| Machine weight | ||
| 4900KG | ||
| Operating environment | ||
| Temperature | 20-30℃ | |
| Relative humidity | 35 - 65%, non-condensing. | |
| Power requirements | ||
| 209-231V , single phase, 50/60hz, 25A(printer), 30A(vacuum motor) | ||
| Warranty period | ||
| One year (please consult your local dealer for details) | ||
