| Specification Data | |||
| Printing technology | |||
| Printhead | EPSON industry level piezoelectric inkjet head | ||
| Inkjet speed | R20 | R32 | |
| Express mode | 145sqm/hr | 178sqm/hr | |
| Production mode | 73sqm/hr | 90sqm/hr | |
| Quality mode | 55sqm/hr | 67sqm/hr | |
| Resolution | Up to 720*2400dpi | ||
| Ink type | LED UV ink | ||
| Color scheme | CMYK, CMYK LCLM, 4 colors/6 colors, CMYK+white | ||
| LED UV lamp | LED cold light source with low energy consumption, long working life | ||
| Cartridge capacity | 1.5L/color | ||
| Media handling system | |||
| Media loading | Roll-to-roll industry feeding&take-up device with tension system | ||
| Media height | Max 3mm | ||
| Printing format | 2000*500000mm | 3200mm*500000mm | |
| Data transfer | |||
| Data interface | High speed USB port (USB 3.0) | ||
| RIP software | Flora edition Photoprint, Caldera, Onyx for option | ||
| PC configuration | Windows 7, CPU i7, RMA 8GB | ||
| Color management | ICC based color, adjustment curves, density adjustment | ||
| File format | Tiff, Jpeg, Postscript, PDF, EPS, etc | ||
| Dimensions | |||
| Printer dimension | 3528*1400*850mm | 4728*1400*850mm | |
| Printer weight(Net/Gross) | 550kgs/620kgs | 700kgs/780kgs | |
| Package dimension | 3650*1500*1000mm | 4850*1500*1000mm | |
| Environment requirements | |||
| Temperature | 30-35℃ | ||
| Humidity | 20-80% humidity, non-condensing | ||
| Power requirements | |||
| Printer | Single phase AC 210V-230V, 50/60HZ, 16A, max 3500W | ||
| Dryer | / | ||
| Air | / | ||
| Warranty | |||
| 12 months (Please contact local distributors for more information.) | |||
