| Printing technology | ||
| Printhead Qty | EPSON S3200 (48 printheads) | |
| Printing speed | Draft mode | 800M²/h |
| Express mode | 420M²/h | |
| Production mode | 280M²/h | |
| Quality mode | 220M²/h | |
| Print Resolution | Max. 2400dpi | |
| Ink solution | ||
| Ink type | Reactivity/Pigment/Acidity/Dispersion | |
| Color scheme | 12 colors | |
| Cartridge capacity | 10L/color | |
| RIP software | NeoStampa, support for third-party software | |
| Media system | Belt conveyor | |
| Media specification | Small rolls up to 400mm diameter, gas expansion shaft loading and unloading,A-frame unwinding (diameter 1200) | |
| Media width | 1900mm | |
| Media type | Cotton, linen, silk | |
| Data transfer | ||
| Data interface | fiber-optical | |
| PC Specification | CPU:I9 7th generation or above, RAM:32G, ROM:2T | |
| Dimensions | ||
| Machine dimension | 4.7 x 4 x 2m | |
| Weight | 8T | |
| Package dimension | 5*2.3*2.35m (2 sets) | |
| Operation envivornment requirements | ||
| Temperature | 25~28℃ | |
| Humidity | 60%-70% (no-condensing) | |
| Power & Air pressure requirements | ||
| Power | Printer Machine: 20KW(380V,3-phase) | |
| Dryer: 60KW | ||
| Warranty | ||
| 12 months(Please contact local distributors for more information.) | ||
-Industrial high-quality sticky belt
Seamless industry-grade belt, controlled by advanced software tech, to make sure fabric movement stable and accurate.
-Auto printhead cleaning and moisturizing system
Equipped with printhead auto ink wiping, cleaning and moisturizing system, to protect printhead and prolong head life-times.
-Efficient ink circulation system
Ink circulation keeps ink supply great fluency to ensure continunous printing and color performance, and protect printheads.
-Mode switch for different fabric printing
Automatic switch modes among knitting, woven, elasstic and nonelastic fabrics. Widely applied for different fabrics printing and ink solutions.
-Smart control system
Applying PLC for whole machine control to strengthen system stability. Friendly touch panel is applied to ease printer operation and saving manpower cost.
-Double guide-beam construction
Double guide beam construction for smoother running
