| Model | X3 |
| Printhead Qty | 4-8 EPSON injustrial head |
| Printheads | 4-8 EPSON injustrial head |
| Printing speed | |
| Draft mode | 300 m2/h |
| Production mode | 220 m2/h |
| Quality mode | 180 m2/h |
| Resolution | 508*600dpi / 508*1200 dpi / 508*1800dpi |
| Ink type | reactive ink, pigment ink |
| Color configuration |
K-C-M-Y-O-R-B-Lk K-C-M-Y-Lm-R-B-K |
| Cartridge capacity | 10L/color |
| RIP software RIP | NeoStampa |
| Media handling | Sticky belt |
| Media specification | Max coil diameter 400mm, max width 2000mm |
| Printing width | 2000mm |
| Media width | 2000mm |
| Media type | cotton, linen, silk, etc |
| Data interface | optical fiber |
| PC specificaiton | CPU: I7, RAM:16G, ROM：500GB |
| Dimension | |
| Machine dimension | 4270*2210*1970mm |
| Net weight | 3500KGS |
| Height of belt | 965mm |
| Package dimension | 4500*2400*2300mm*1 |
| Environment requirements | |
| Temperature | 25~28℃ |
| Humidity |
60%~70% no-condensing |
| Power requirements | |
| Printer | 12KW(380V, 20A) |
| Dryer | 30KW |
| Air | clean and dry air ≥0.6Mpa, 0.6m³/min, gasholder≥30L |
Industrial high-qulaity sticky belt
Seamless industry-grade belt, controlled by advanced software tech, to make sure fabric movement stable and accurate.
Belt cleaning system
Complete system of brush roller, sponge roller, gluing roller, to keep sticky belt clean and fully functional.
Auto printhead cleaing and moisturizing system
Equipped with printhead auto ink wiping, cleaning an moisturizing system, to protect printhead and prolong head life-time.
Efficient ink circulation system
Ink circulation keeps ink supply great fluency to ensure continunous printing and color performance, and protect printheads.
Mode switch for different fabric printing
Automatic switch modes among knitting , woven, elasstic and nonelastic fabrics. Widely applied for different fabrics printing and ink solutions.
Smart control system
Applying PLC for whole machine control to strengthen system stability. Friendly touch panel is applied to ease printer operation, saving manpower cost.
Wide applications
--garments
--bedcloths
--fashion accessories
--home textiles
--wall cloths
--table cloths
--furniture textile
Various applicable fabrics
--cotton
--polyester
--fibre
--silk
--nylon
--Lycra
--wool
--blending fabric
