| Printing technology | |
| Printhead | EPSON S3200-A1，24 |
| Printing speed |
Express Mode 2000M²/h Quanlity Mode 1000M²/h |
| Printhead maintain | Automatic cleaning and moisturizing |
| Ink solution | |
| Ink type | Dye sublimation ink、Pigment ink |
| Color scheme | 6 colors |
| Cartridge capacity | 10L/color |
| Ink supply mode | Automatic degassing, automatic negative pressure, ink circulation |
| Media handling system | |
| Media loading | roll to roll |
| Media dimension | Max. roll diameter 1100mm, Max.weight 1200KG |
| Printing format | Max. 3200mm |
| Media format | Max. 3250mm |
| Media type | Heat transfer paper, wood grain paper, corrugated paper, film, etc., the minimum weight of 31g |
| Data transfer | |
| Data interface | Optical data communication，USB3.0 |
| Rip software | FLORA ，NeoStampa，ONYX，other |
| Dimensions | |
| Machine size | Net size（L×W×H）：5550×1400×2300mm Package size（L×W×H）：5700×1400×2350mm |
| Rewinding size | Net size（L×W×H）：3760×1300×1150mm Package size（L×W×H）：3950×1550×1450mm |
| Net weight | Machine is 3000KG, Winding is 700KG |
| Environment requirements | |
| Temperature | 25~28℃ |
| Humidity | 60%~70% no-condensing |
| Power & Air pressure requirements | |
| Power |
Machine：AC380V±10％ 50/60HZ 20A Dryer：AC380V±10％ 50/60HZ 63A |
| Air | Clean and dry air ≥0.6Mpa, 0.6M3/min, Air tank≥30L |
| Warranty | |
| 12 months(Please contact local distributors for more information.) | |
-Media transmission
Constant tension control technology to make precise step.
Make sure the printing has no contact marks and no misplace at both direction.
-Production efficiency
Multi-printheads splicing technology, can run single pass with a amazing scan width.
Production efficiency doubled and let customers reduce purchase cost.
-Rewind and unwind system
Unwind system support 10000m material, rewind system support 1000m material.
Low material loss , effectively reduce the material cost.
-Material drier
Automatic constant-temperature drying system.
Adjust according to demand, more energy efficient.
-Auto clean
Printhead automatic wipe cleaning system.
Maintenance is simple , improving production speed effectively.
-Circulation
Ink circulation system.
Printing is more stable and smooth.
-Intelligent control
PLC and touch panel interface, to enable a more stable.
Convenient and humanized system.
