| Print Technology | ||
| Print head | Industrial print head, 5pl drop size | |
| Resolution | 1200dpi native resolution | |
| Productivity | 100m/min-150m/min | |
| Inks | ||
| Ink type | Water-base single pass corrugated board special ink | |
| Color | CMYK | |
| Cartridge | 15L/color | |
| Media Handle | ||
| Media system | Conveyor belt with vacuum adjustable platform | |
| Media handling | Auto loading from 500mmx500mm - 2500mmx2500mm | |
| Printing width | F2200mm | |
| Media width | 2500mm | |
| Media thickness | 2-20mm | |
| RIP/Data interface | ||
| RIP software | Photoprint , Onyx, Caldera | |
| Data interface | 10G Base-SR | |
| Dimension/Weight | ||
| Machine dimension | 15000*7500*2400mm | |
| Weight | 11.5 tons | |
| Installation Condition | ||
| Operation condition | 20～30℃, 40～70%, non condensation | |
| Best condition | 22.5～27.5℃, 45～65%, non condensation | |
| Compress air | 6 bar | |
| Power supply | Printer | 380V AC, 50-60HZ, 40KW |
| Heater | 380V AC, 50-60HZ, 60KW | |
| Feeder | 380V AC, 50-60HZ, 20KW | |
|
*the final specification of the machine is subject to actual product. Please contact the sales manager for the latest specification data. *The company reserves the right of final interpretation of this brochure. |
||
· Reduce labor cost, reduce waste cost and reduce the inventory
· Faster job turns, optimal choice for short run, medium and large runs
· High integration with coating system, heating system and slotting system.
- Single pass technology with DOD piezo inkjet techonology
- Print resolution up to 1200dpi
- Standard CMYK configuration with AQ ink
- Up to 150m/min
- Substrate size up to 2.5mx2.5m
- Inline coating and slotting system
- Automatic cleaning system
- Suitable for all kinds of yellow, white card and kraft paper etc.
