| Print Technology | ||
| Print head | Piezoelectric inkjet technology(DOD), 4 level grayscale | |
| Resolution | Max 600×1200dpi | |
| Productivity | Draft mode：1200㎡/hr | |
| Express mode：600㎡/hr | ||
| Production mode：400㎡/hr | ||
| Quality mode：300㎡/hr | ||
| Inks | ||
| Ink type | AQ ink | |
| Color Option | CMYK | |
| Ink Tank Capacity | 5L/C | |
| Media Handle | ||
| Material transfer | Strong vacuum table, Industrial belt transmission | |
| Max. Media size |
Standard size: 2500 × 1500mm Max.size: 2500 × 4000mm (custom brackets required) |
|
| Thickness | 1.5-20mm (Printer supports media thickness < 50mm) | |
| Max. Print width | Max. 2500mm | |
| Feeder&Stacker | ||
| Auto feeding size | 500mm-2500mm | |
| Auto stacking size | < 2500mm(Optional) | |
| RIP/ Data Interface | ||
| Data Interface | USB 3.0 | |
| RIP | Photoprint /Onyx, open for the third part RIP | |
| Dimension/Weight | ||
| Machine | 5300 × 3950 × 1820mm，5500kg | |
| Printing Unit | 5500 × 2180 × 2240mm，3800kg | |
| Feeder | 4500 × 1450 × 2140mm，2800kg | |
| Stacker | 3400 × 1780 × 1800mm，1500kg | |
| Operation Condition | ||
| Environment | Low dust, less light | |
| Temperature | 20-35℃，(ideal condition) | |
| Relative humidity | 50%~70%(ideal condition) | |
| Installation Requirements | ||
| Power supply | AC380-400V，3 Phase，40A，50/60Hz，15kW | |
| Compress air | Dry compressed air，6-8 bar | |
| Warranty | ||
| One year (Please consult your local deler for details) | ||
|
*the final specification of the machine is subject to actual product. Please contact the sales manager for the latest specification data. *The company reserves the right of final interpretation of this brochure. |
||
-Three rows of print heads, multiple configuration
- Standard CMYK, satisfy most of customer's request
- Support online upgrade, configuration upgrade from economy version to high-speed version
-Automatic cleaning & moisturizing system
- Automatic cleaning system, simple and convenient maintenance
- Automatic moisturizing system, greatly reduce the maintenance times of print head，improve production efficiency
-Industrial belt conveyor, vacuum adsorption
Industrial belt conveyor, strong vacuum suction, greatly ensure the smoothness of the sbustrates Ensure paper feeding accuracy to feed evenly
-Auto-stacker system(optional)
Automatic stacker system
Max. media size up to 2500×1350mm
-Friendly GUI, easy operation
PLC real-time displays the printer status The friendly GUI is easy to learn and operate, able to calculate the ink volume for each printing job
-Auto-feeder
Automatic feeding system, save labor, increase productivity
Max. media size up to 2500×1500mm
